HIKVISION 32 CHANNELS NVR 12MP – 4x SATA – AL 24IN/4OUT-POE

Model: Hikvision DS-7732NI-I4/24P

32-ch 1.5U 24 PoE 4K NVR

Features

• Up to 32 channel IP cameras can be connected
• Up to 2-ch @ 12 MP/16-ch @ 1080p decoding capacity
• 2 HDMI and 1 VGA interfaces: HDMI interfaces support independent video output
• 4 HDDs for continuous video recording
• Plug & Play with 24 Power-over-Ethernet (PoE) interfaces
• Supports various special function cameras, including thermal camera/fisheye/people counting/heatmap/ANPR (automatic number plate recognition)
• Advanced streaming technology enables smooth live view and data self-correction in poor network conditions
• Supports dual-stream recording to save time and bandwidth

Specifications

Video And Audio

• IP Video Input: 32-ch
• HDMI 1 Output
• HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,VGA1:
  2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• HDMI 2 Output: 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• VGA Output: HDMI,VGA
• CVBS Output: 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
• Incoming Bandwidth: 256 Mbps,320Mbps
• Audio Output: 1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 k Ω)

Decoding

• Decoding Format: H.265+,H.265,H.264+,H.264
• Decoding Capability: 2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (30fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps)
• Synchronous Playback: 16-ch
• Recording Resolution: 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF /DCIF/ 2CIF/CIF/QCIF

Network

• Network Protocol: TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SNMP, SMTP, NFS, iSCSI, UPnP™, HTTPS
• Remote Connection: 128
• Network Interface: 1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE

• Interface: 24-ch
• Power: ≤ 210W
• Standard: IEEE 802.3 af/at

RAID

• RAID Type: No

Auxiliary Interface

• SATA: 4
• ESATA: 1 eSATA interface
• Capacity: Up to 8 TB capacity for each HDD
• Serial Interface: 1 RS-485 (half-duplex), 1 RS-232
• USB Interface: Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
• Alarm In/Out: 16/4 (Optonal: 16/8)

General

• Power Supply: 100 to 240 VAC,≤ 360 W
• Consumption: ≤ 20 W
• Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity: 10 to 90 %
• Dimension (W × D × H):
  • 445 × 400 ×71 mm ( 17.5″× 15.7″ × 2.8″)
  • ≤ 5 kg (11 lb)
